Scope of Application

This standard is applicable to the small size signal conversion function of LVSD/TTL signal points on industrial control motherboards, reducing the development cycle of LCD screens of different sizes on motherboards

2. Product Function Description

LVDSL to TTL conversion

1. Convert a single 6-bit LVDS signal into a TTL signal to directly drive the TFT LCD screen

2. Comes with LCD screen backlight driver circuit

TTL to TTL conversion

1. Use AT070TN83/AT070TN83V.1 screen 40PTTL signal to convert to 50P or 60P TTL signal to directly drive the screen

2. Comes with backlight driver circuit, no need for external LED driver

Please specify the functions and interfaces when purchasing

3. Working environment

4.1 Working temperature: -20 ℃ to+70 ℃

4.2 Working humidity: 90% RH (no condensation allowed)

4. Save the environment

5.1 Storage temperature: -20 ℃ to+80 ℃

5.2 Storage humidity: 90% RH (no condensation allowed)
